Modes Of Ventilation :
Volume Controlled Ventilation-
VC-CMV
VC-AC
VC-SIMV
PRVC-CMV
PRVC-AC
PRVC-SIMV
Pressure Controlled Ventilation-
Spontaneous Breathing Support-
PS/CPAP (PSV) with Apnea Backup Ventilation
APRV
HFNC
Therapy type -
Invasive Ventilation
Non-invasive Ventilation (NIV)
O2 therapy
Types of Patients Supported- Adults and Paediatrics
Apnea Backup Ventilation
Hign Flow Nasal Oxygen Therapy
Respiratory Rate (RR) - 1-60 BPM
Peak Inspiratory Pressure- 60cm H2O
PEEP - 0-40 cm H20
Pressure Support - 0 - 50 cm H2O
Inspiratory Time (Ti) - 0.2 - 5 s
PEEP - 0 - 50 cm H2O
I:E Ratio - 1:6 to 6:1
Tidal Volume (VT) - 50-2000 ml
Inspiratory Flow Rate - 280 L/min (Internally restricted to 160 L/min)
Trigger Flow Sensitivity - 1-20 L/min
Volume Accuracy - 2- 3% of full scale between 10 L/min - 80 L/m
O2 concentration(FiO2) - 21 -100%
FiO2 control - Closed loop electronic manipulationoooo
Recruitment Tools - Inspiration Hold, Expiration Hold
Leak Detection and Compensation - Yes
SIGH - Programmable
O2 Therapy :
Continuous flow - 0 - 100 L/min
Concentration - 21 - 100 %
Nebulizer - for 5, 6, 7, 8, 9, 10 minutes
Synced with Inspiratory Phase
Oxygen Input - 45 - 60 PSIG
Screen - 10” TFT LCD Touchscreen
Dimensions Patient Unit - 395 X 340 X 255 mm
Weight - 10.1 Kg Patient Unit , 25 Kg with trolley
Battery - Lithium, Internal
Battery Back-up Time - Upto 8 hours
Mains Input - 200 - 240V AC, 50 - 60 Hz
Input Current - <2.00 A
Power Consumption - <150W
