Application: Adult, pediatric and neonate
-
Dimension: 34cm (L) X 28cm (H) X 14.8cm (W)
-
Weight: 4.84 Kg(Inclusive of 1 Li-ion battery)
-
Power supply: AC 100-240 V 50 Hz / 60 Hz, 12 V D.C input Defibrillator & cautery protected Safety Class: Category I
-
Display: 12.1” touch screen high resolution color TFT LCD display
-
Resolution: 800×600 pixels or higher
-
Battery Type: Rechargeable Lithium ion batteries
-
Battery back up: >240 minutes (2 batteries 480 minutes) (2nd battery optional)
-
Battery charging time: <6 hours(2 batteries, 12 hours)
-
Recorder (optional) :
Method: Thermal dot array
Paper width: 50 mm
Paper speed: 12.5 / 25 / 50 mm/sec
Trace: Max 3 tracks
Level: Low, medium & high
Indication: Auditory & visual
Setup: Default & custom
Silence: All alarms can be silenced
Operating temperature : 5°~40° C
Storage temperature : -20° to +55° C
Operating humidity : 15% to 85% (non condensing)
Storage humidity : 10% to 93% (non condensing)
Operating atmospheric pressure : 700hPa to 1060 hPa
Storage atmospheric pressure : 500 hPa to 1060 hPa
Method: Automatic Oscillometric
Operation modes: Single (manual), Cycle (automatic), STAT (continuous)
for adult & pediatric
Single (manual), Cycle (automatic) for neonates
Measurement: Systolic pressure, Diastolic pressure, Mean arterial pressure(MAP)
Range: Adult: 10-270 mmHg
Pediatric: 10-235 mmHg
Neonate: 10-135 mmHg
Unit: mmHg / Kpa selectable
Auto measurement: 1,2,3,4,5,10,15,30,45,60,90,120,240,480 minute
1000 groups NIBP data review
Leads: I, ll, lll, aVR, aVL, aVF,V
Gains: Auto, 0.25x, 0.5x, 1x, 2x, 4x
Input impedance: 5 M ohm
Common Mode Rejection ratio: 89dB (Diagnostic mode)
105dB (Monitor mode)
105dB (Surgical mode)
Bandwith: 0.5-40 Hz (Monitoring mode)
0.05-150 Hz (Diagnostic mode)
1-25 Hz (Surgical mode)
Indication of detachment of electrodes (exclusive of RL)
Scanning speed :6.25mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s
Heart Rate range : Adult:10-300 bpm
Pediatric and Neonate: 10-350 bpm
Accuracy: ±1 bpm or ±1 % whichever is greater
Method: Thoracic Impedance method
Measuring range: 0-150 rpm
Accuracy: ±2 rpm
Gain: x0.25, x1, x2, x4
Sweep speed: 6.25 mm/s, 12.5 mm/s, 25 mm/s
Apnea alarm delay: 10s, 15s, 20s, 25s, 30s, 35s, 40s, 45s, 50s, 55s, 60s
Range: 0°C-50°C
Unit: Centigrade (°C), Fahrenheit (°F)
Resolution: 0.1°C
Accuracy: ±0.1°C
Alarm range: 0°C-50°C
Range: 0-100%
Accuracy: ±2% (70-100%), (0-69%) unspecified
Pulse rate range: 20 – 250 bpm
Pulse rate accuracy: ±1 or 1%, whichever is greater
