Technical Specification-
Operating Specifications
Ventilation Modes IPPV;ASSIST;CPR
Operating Pressure 2.7 to 6.0 bar
I:E Ratio Constant 1:1.67
Minute Volume (MV) Continuously variable from 3 to 20 l/min (ATPD)
Ventilation Frequency Continuously variable from 5 to 40 min-1
Trigger Sensitivity -2 mbar Deviation ±0.5mbar
O2 concentration 40% & 100%
MV tolerances ±20%
Max. Ventilation Pressure 20 to 60 mbar
Safety Airway Pressure ≤75 mbar
Pressure Gauge Accuracy 0 to 60 mbar Deviation ±5%
Respiratory Compliance 100 ml/cmH2O
Voice Alarm Mute Time ≤ 120s
Patient Valve Resistance
Inspiration <6 mbar at 30 to 60 l/min
Expiration <6 mbar at 30 to 60 l/min
Emergency air intake <6 mbar at 15 to 30 l/min
Physical Characteristics
Display 2.4” TFT color display resolution ratio: 320X240
Dimensions 240×120×100mm include
WxHxD in mm connectors
Weight Approx. 1.3kg
Power Supply
External Power Source AC: 100 to 240V ; 1.5 to 4A ; 50/ 60HZ DC: 12 V Adapter
Inbuilt Power Source Lithium battery 7.4V; 3400mAh;
operating time : more than 10 hours
General Specifications
Type of Protection against Electric Shock Class II Equipment with
Internal power supply
Degree of protection against Electric Shock BF
Degree of Protection against Hazards of Explosion Ordinary equipment, without protection against explosion; not for use with flammable anesthetic
Operating
Temperature range -20°C to + 50°C
Humidity 15% to 95%
Air pressure 70 kPa to 110 kPa
Store / Transport
Temperature range -40°C to + 50°C
Humidity ≤95%
Air pressure 70 kPa to 110 kPa
Required / Standard gas supply
Supply pressure At least 2.7 bar
Drawn flow At least 70 1/min Oxygen (ATPD)
Optimal gas supply
Supply pressure At least 4.5 bar
Drawn flow At least 100 1/min Oxygen (ATPD)
Non-recommended gas supply
Supply pressure Less than 2.7 bar
Drawn flow Less than 80 1/min Oxygen (ATPD)
Standard Accessories
Oxygen Inlet Connection Hih Pressure Hose With Female Thread 9/16-18 UNF
Resuable Ventilation Hose Spiral Silicone for Adult
Resuable Ventilation Mask Silicone Mask with Silicone Head Gear for Adult
Optional Accessories
Oxygen Cylinder, Carry Bag, Ventilator Mount
