Contec ECG300GA 3 Channel ECG
product thumbnail

Contec ECG300GA 3 Channel ECG

SKU: PROD68
Price : ₹26,000
Price Includes Shipping
( 0 reviews )

ECG300GA is an Electrocardiograph which can collect 12-lead ECG signal and print waveform by the thermal printing system. It features in, recording and displaying ECG waveform in AUTO/Manual mode, measuring and diagnosing ECG waveform parameters automatically, prompting for “Lead off” and “Lack of paper”, multi-language interface, AC/DC, selecting any rhythm lead, case database management.

Add To Cart
  • Input mode: floating and defibrillation protection
  • Frequency response: 0.05Hz ~ 150Hz(-3dB~+0.4dB)
  • CMRR: >60dB, >100dB(add filter)
  • Time constant: ≥ 3.2s
  • Patient leak current: <10µA
  • Calibration voltage: 1mV
  • Sensitivity: 2.5, 5, 10, 20, 40 mm/mV ±5%, standard sensitivity: 10mm/mV±2%
  • Noise level: <15µVp-p
  • Input circuit current: ≤50nA
  • Input impedance: ≥50MΩ
  • Sampling accuracy: 12-bit
  • Safety classification: class I, type CF and defibrillation-proof applied part
  • Recording mode: thermal printing system
  • Auto record: set record according to auto record format and mode, automatically switching leads, measuring and analyzing.
  • Rhythm record: set record according to rhythm record format and mode, automatically measuring and analyzing.
  • Manual record: set record according to record format, manually switching leads.
  • Measurement parameters: HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1)
  • Paper size: 80mm(W)×20m(L)
  • Sampling frequency: 1000Hz
  • EMG interference filter: 25Hz/35Hz (-3dB)
  • Power frequency filter: AC 50Hz/60Hz(-20dB)
  • Paper speed:
Auto: 25, 50mm/s, ±5%
Rhythm: 25, 50mm/s, ±5%
Manual: 5, 6.25, 10, 12.5, 25, 50mm/s, ±5%
  • Power supply:
AC: 100V~240V(50/60Hz)
DC: 7.4V/3500mAh rechargeable lithium battery
  • Fuse specification: two AC time lag fuse(φ5×20mm), T1.6AL250V
  • Waterproof degree: IPX0
  • Working mode: continuous working

  • Temperature: 5?~40?
  • Relative humidity: 25%~95%(non-condensing)
  • Atmospheric pressure: 700hPa~1060hPa
  • Transport and storage environment
  • Temperature: -40?~+55?
  • Relative humidity: ≤95%
  • Atmospheric pressure: 500hPa~1060hPa
  • Dimension: 315mm(L) × 215mm(W) × 77mm(H)
  • Weigh: 1.6Kg
