Input mode: floating and defibrillation protection
-
Frequency response: 0.05Hz ~ 150Hz(-3dB~+0.4dB)
-
CMRR: >60dB, >100dB(add filter)
-
Time constant:≥ 3.2s
-
Patient leak current: <10µA
-
Calibration voltage: 1mV
-
Sensitivity: 2.5, 5, 10, 20, 40 mm/mV ±5%, standard sensitivity: 10mm/mV±2%
-
Noise level: <15µVp-p
-
Input circuit current: ≤50nA
-
Input impedance: ≥50MΩ
-
Sampling accuracy: 12-bit
-
Safety classification: class I, type CF and defibrillation-proof applied part
-
Recording mode: thermal printing system
-
Auto record: set record according to auto record format and mode, automatically switching leads, measuring and analyzing.
-
Rhythm record: set record according to rhythm record format and mode, automatically measuring and analyzing.
-
Manual record: set record according to record format, manually switching leads.
-
Measurement parameters: HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1)
-
Paper size: 80mm(W)×20m(L)
-
Sampling frequency: 1000Hz
-
EMG interference filter: 25Hz/35Hz (-3dB)
-
Power frequency filter: AC 50Hz/60Hz(-20dB)
-
Paper speed:
Auto: 5, 6.25, 10, 12.5, 25, 50, 100mm/s, ±5%
Rhythm: 5, 6.25, 10, 12.5, 25, 50, 100mm/s, ±5%
Manual: 5, 6.25, 10, 12.5, 25, 50, 100mm/s, ±5%
-
Dimension: 315mm(L) × 215mm(W) × 92mm(H)
-
Weigh: 1.7Kg
